BLACKBURNS METALS LIMITED
Stainless Steel
Pipe Sizes
Pipe
OD
SCHEDULE 5S SCHEDULE 10S SCHEDULE 40S SCHEDULE 80S
Size
1
⁄
8
10.3 - 1.24 1.73 2.41
1
⁄
4
13.7 - 1.65 2.24 3.02
3
⁄
8
17.1 - 1.65 2.31 3.20
1
⁄
2
21.3 1.65 2.11 2.77 3.73
3
⁄
4
26.7 1.65 2.11 2.87 3.91
1 33.4 1.65 2.77 3.38 4.55
1
1
⁄
4
42.2 1.65 2.77 3.56 4.85
1
1
⁄
2
48.3 1.65 2.77 3.68 5.08
2 60.3 1.65 2.77 3.91 5.54
2
1
⁄
2
73.0 2.11 3.05 5.16 7.01
3 88.9 2.11 3.05 5.49 7.62
3
1
⁄
2
101.6 2.11 3.05 5.74 8.08
4 114.3 2.11 3.05 6.02 8.56
5 141.3 2.77 3.40 6.55 9.53
6 168.3 2.77 3.40 7.11 10.97
8 219.1 2.77 3.76 8.18 12.70
10 273.1 3.40 4.19 9.27 12.70
12 323.9 3.96 4.57 9.53 12.70
14 355.6 3.96 4.78
- -
16 406.4 4.19 4.78
- -
18 457 4.19 4.78
- -
20 508 4.78 5.54
- -
22 559 4.78 5.54
- -
24 610 5.54 6.35
- -
30 762 6.35 7.92
- -
