BLACKBURNS METALS PRODUCT CATALOGUE - page 9

7 Aluminium - EXTRUSIONS
Size Weight
(in) per metre (Kg)
1 x 1⁄2 x 16 swg 0.31
11⁄2 x 3⁄4 x 16 swg 0.48
11⁄2 x 1 x 16 swg 0.52
11⁄2 x 1 x 10 swg 1.00
2 x 1 x 10 swg 1.22
2 x 11⁄2 x 10 swg 1.34
3 x 1 x 10 swg 1.67
3 x 11⁄2 x 10 swg 1.90
Size Weight
(in) per metre (Kg)
3 x 13⁄4 x 10 swg 2.01
3 x 2 x 10 swg 2.11
4 x 1 x 10 swg 2.12
4 x 13⁄4 x 10 swg 2.45
4 x 2 x 10 swg 2.56
6 x 2 x 10 swg 3.40
6 x 3 x 3⁄8 swg 10.80
Box Section
RECTANGULAR
ALLOYS: 6063-T6, 6082-T6
Size Weight
(in) per metre (Kg)
1 x 10 swg 0.59
Ladder Rung
ALLOY: 6082-T6
Size Weight
(in) per metre (Kg)
1⁄
2 x 1⁄2 x 16 swg 0.20
3⁄4 x 3⁄4 x 16 swg 0.31
3⁄4 x 3⁄4 x 10 swg 0.56
1 x 1 x 16 swg 0.42
1 x 1 x 10 swg 0.78
11⁄4 x 11⁄4 x 16 swg 0.53
11⁄4 x 11⁄4 x 10 swg 1.00
11⁄2 x 11⁄2 x 16 swg 0.64
11⁄2 x 11⁄2 x 10 swg 1.23
Size Weight
(in) per metre (Kg)
13⁄4 x 11⁄4 x 10 swg 1.45
2 x 2 x 16 swg 0.87
2 x 2 x 10 swg 1.68
2 x 2 x 1⁄
4 swg 3.06
21⁄
2 x 21⁄
2 x 10 swg 2.12
3 x 3 x 10 swg 2.57
4 x 4 x 10 swg 3.47
4 x 4 x 1⁄4 swg 6.56
Box Section
SQUARE
ALLOYS: 6063-T6, 6082-T6
Metric Box Section
ALLOY: 6065
Size Weight
(mm) per metre (Kg)
50 x 50 x 3.0 1.53
