Curved Elbow
Item No. Application
Material Dimensions
E450
for tube
Ø
42.4 x 2.0mm AISI 316 A = 65mm
E450/26 for tube
Ø
42.4 x 2.6mm AISI 316 A = 65mm
E2002 for tube
Ø
48.3 x 2.0mm AISI 316 A = 73mm
E2002/26 for tube
Ø
48.3 x 2.6mm AISI 316 A = 73mm
90
o
Mitred Elbow
Item No. Application
Material Dimensions
E451
for tube
Ø
42.4 x 2.0mm AISI 316 A = 65mm
E451/26 for tube
Ø
42.4 x 2.6mm AISI 316 A = 65mm
E2012 for tube
Ø
48.3 x 2.0mm AISI 316 A = 67mm
E2012/26 for tube
Ø
48.3 x 2.6mm AISI 316 A = 67mm
Adjustable Elbow
Item Application
Material
Dimensions
No.
E446 for tube
Ø
42.4 x 2.0mm AISI 316 A=97mm B=22mm
E446/26 for tube
Ø
42.4 x 2.6mm AISI 316 A=97mm B=22mm
E4462 for tube
Ø
48.3 x 2.0mm AISI 316 A=109mm B=25mm
E4462/26 for tube
Ø
48.3 x 2.6mm AISI 316 A=109mm B=25mm
Internal Connector
Item Application
Material
Dimensions
No.
E455 for tube
Ø
42.4 x 2.0mm AISI 316A=54mm B=25.5mm
E455/26 for tube
Ø
42.4 x 2.6mm AISI 316A=54mm B=25.5mm
E2062 for tube
Ø
48.3 x 2.0mm AISI 316A=55mm B=25.5mm
E2062/26 for tube
Ø
48.3 x 2.6mm AISI 316A=55mm B=25.5mm
