Mitred Elbow
Item Application
Material
Dimensions
No.
E2015 for tube
Ø
42.4 x 2.0mm AISI 316
A=50mm
E2017 for tube
Ø
48.3 x 2.0mm AISI 316
A=55mm
Adaptor
Item Application
Material
Dimensions
No.
E454 for tube
Ø
42.4 x 2.0mm AISI 316 A=27mm B=20mm
E454/26 for tube
Ø
42.4 x 2.6mm AISI 316 A=27mm B=20mm
E2052 for tube
Ø
48.3 x 2.0mm AISI 316 A=31mm B=22mm
End Connector
Item Application
Material
No.
E4842 for tube
Ø
42.4 x 2.0mm AISI 316
E4843 for tube
Ø
42.4 x 2.6mm AISI 316
Elbow with
Wall Flange
(radius)
Item Application
Material
Dimensions
No.
E4561 for tube
Ø
42.4 x 2.0mm AISI 316 A=84mm B=100mm
E4562 for tube
Ø
42.4 x 2.6mm AISI 316 A=94mm B=105mm
