166
www. bl ackburnsmeta l s . com
Tube
LGD: 6000mm
Item No.
Application
Material Weight (kg)
E1000424 for tube
Ø
42.4mm AISI 304 ca.11
E1000483 for tube
Ø
48.3mm AISI 304 ca.13
E1100424 for tube
Ø
42.4mm AISI 316 ca.11
E1100483 for tube
Ø
48.3mm AISI 316 ca.13
Vertical 90
o
Item No.
Application
Material Weight (kg)
E1500100 for tube
Ø
42.4mm AISI 316 0.362
E1500110 for tube
Ø
48.3mm AISI 316 0.440
Horizontal 90
o
Item No.
Application
Material Weight (kg)
E1400100 for NR
Ø
42.4mm AISI 316 0.286
E1400110 for NR
Ø
48.3mm AISI 316 0.400
Rubber Inserts
Item No. Application
E1999100 Insert to suit glass thickness 8 - 10.76mm for NR 42.4mm
E1999200 Insert to suit glass thickness 12 - 16.76mm for NR 42.4mm
E1999300 Insert to suit glass thickness 16.76 - 18mm for NR 42.4mm
E1999400 Insert to suit glass thickness 8 - 13mm for NR 48.3mm
E1999500 Insert to suit glass thickness 14 - 18mm for NR 48.3mm
E1999600 Insert to suit glass thickness 18 - 20.76mm for NR 48.3mm
