10mm Thick Toughened Monolithic Clear Float Glass
Use with our fully assembled posts with glass clamps
15mm & 19mm Thick Toughened Monolithic Clear Float Glass
Use with our aluminium glass channel systems such as PanelGrip & PanelWedge
17.5mm & 21.5mm Thick Toughened & Laminated Clear Float Glass
Use with our aluminium glass channel systems such as PanelGrip & PanelWedge
• Suits standard height uprights installed at 1200mm centre to centre
• Polished edges
• 3mm radiussed corners
• No security pin holes required
• Use with type 401 & 402 glass clamps
• Suits our PanelGrip & PanelWedge types of channel – base or side fixed
• Polished edges
• 5mm radiussed corners
• Handrail will be required
• Suits our PanelGrip & PanelWedge types of channel – base or side fixed
• Polished edges
• 3mm radiussed corners
Size mm Weight
For Use With
Code
1100 x 925 x 10 25.44Kg
Fully assembled posts
or 401 or 402 series clamp
1855101100925
Size mm Weight
For Use With
Code
1000 x 1075 x 15 40.32Kg Base fixed channels set onto
finished floor line
18551510001075
1000 x 1075 x 19 51.42Kg
18551910001075
1000 x 1175 x 15 44.07Kg Side fixed channels set 100mm
below finished floor line
18551510001175
1000 x 1175 x 19 56.20Kg
18551910001175
Size mm Weight
For Use With
Code
1000 x 1075 x 17.5 47.04Kg
Base fixed channel set
onto finished floor line
185617510001075
1000 x 1075 x 21.5 57.76Kg
185621510001075
1000 x 1175 x 17.5 51.41Kg Side fixed channel set 100mm
below finished floor line
185617510001175
1000 x 1175 x 21.5 63.15Kg
185621510001175
1100mm
925mm
1000mm
1000mm
1075 or 1175mm
1075 or 1175mm
27
PRO-GLASS - STANDARD PANELS
