Internal
External
Zinc
304
316
4
Code
Ø mm
1804301FC
42.4
1804301FD
48.3
1806301FC
42.4
1806301FD
48.3
Code
Ø mm
1804301CC
42.4
1804301DD
48.3
1806301CC
42.4
1806301DD
48.3
Code
Ø mm
1804303FC
42.4
1804303FD
48.3
1806303FC
42.4
1806303FD
48.3
Code
Ø mm
1804333FC
42.4
1804333FD
48.3
1806333FC
42.4
1806333FD
48.3
Code
Ø mm
1804305FCB
42.4
1804305FDB
48.3
1806305FCB
42.4
1806305FDB
48.3
Code
1804305FF
Code
Ø mm
1804305FC
42.4
1804305FD
48.3
1806305FC
42.4
1806305FD
48.3
Code
Ø mm
1804315FC
42.4
1804315FD
48.3
1806315FC
42.4
1806315FD
48.3
Code Ø mm Glass mm
1804358G
50
8 - 19
1806358G
50
8 - 19
8mm thread
Glass thickness for 333's is 20mm.
For thicker glass longer threaded
lengths can be purchased
65mm distance from flat to centre
of bracket
65mm distance from tube to centre
of bracket
68mm distance from wall to centre
of bracket
69mm distance from glass to centre
of bracket
63.5mm distance from wall to
centre of bracket
63.5mm distance from wall to
centre of bracket
80mm distance from wall to centre
of bracket
72mm distance from wall to centre of bracket.
Supplied with 8mm screw thread for wall fixing
Code
171166
171169
78mm distance from wall to centre of
bracket
86mm distance from wall to centre of
bracket
Wall/Tube
Wall/Tube
Wall/Flat
Wall/Tube
Wall/Tube
Fixed Spigot
Adjustable Height - Fixed Spigot
Single Wall Mount
Glass/Tube
Handrail Bracket Plate and Rubbers
to Suit Glass Balustrading
Satin Polish Weldable Handrail
Bracket and Cover Plate
Flat/Tube
Tube/Tube
Tops come with 5mm clearance holes. For fixing screws, see page 5.
NEW
Example of Glass Fix, Adjustable
Height and Fixed Spigot
HANDRAIL BRACKETS
