11
Code Group
Style
Fix Type
Ø mm
Glass Clamp Size
L x W x D mm
Glass Thickness
mm
Glass Width
mm
401
•
42.4
•
48.3
•
Flat
63 x 45 x 28
8*, 10 & 12*
1500
4012
•
42.4
•
48.3
•
Flat
67 x 45 x 32
12
1500
440
•
Flat
60 x 70 x 41
15, 17.5*, 19* & 21.5*
1500
402
•
42.4
•
48.3
•
Flat
60 x 55 x 35
8*, 10 & 12*
1500
403
•
42.4
•
48.3
•
Flat
Ø 60 x 28
8*, 10 & 12*
1500
*Requires special glass rubbers, see pages 12 - 13
Extract from BS EN 12600 Loading Tables;
Glass Clamp
Exploded Diagram
Dimensions
Min.
Max.
L - Width of Glass
500mm
See Table Below
T - Glass Thickness
See Table Below See Table Below
B - Height of Glass
800mm
1 metre
B1 - Distance - Handrail to Glass
10mm
50mm without edge protection
120mm with edge protection
B2 - Distance - Bottom to Glass
10mm
50mm without edge protection
120mm with edge protection
F(ver)=100kg
F(ver): maximum permittable
vertical force for 4 glass
clamps (without security pins)
B2
L
B
T
B1
Ø
F(hor)=300kg
F(hor):
maximum
permittable
horizontal
force for 4
glass clamps
GLASS CLAMP SYSTEM BS EN12600 LOADING TABLE
