10
GLASS FIXING INFORMATION
Location plate required
on lower clamp
The most popular method for providing a glazed balustrade, while at the same time keeping the outlook
open and views beyond visible. Glass Clamps are simple to install and are offered in either a square or
radiused option, providing a glazed system between posts. Compatible with 8 to 12mm thick glass,
clamps can be used over any length of installation as well as slopes and staircases.
If using glass clamps in any installation where the glass is fixed to the outside of a staircase and
overhanging, then security pins (189900401) and drilled glass must be used. Alternatively use our
square glass clamps which come with a bottom location plate, so no drilling is required.
Pin - 189900401 required
Pin - 189900401 not required
x
for our new
glass range,
See pages 27 - 29.
GLASS CLAMP SYSTEM
