BLACKBURNS X-TRUDE COMPONENT & ASSEMBLY GUIDE
5
3) BXF-25JS
Pre-cut 5mm aluminium
flat bar which is used as a
join strip between frame
sections (if required)
All are pushed into place
then drilled and riveted
4) BXF-25HB
Pre-cut 1/4 inch end stop
profile at 100mm lengths
which is used as a hook
on fixing bracket
UNIT TYPE
BOX OF 50
MILL FINISH
BOX
n
n
UNIT TYPE
BOX OF 50
MILL FINISH
BOX
n
n
4mm holes evenly spaced across the centre of the bracket
used for mounting back to a suitable fixing background
