MIC6
®
Specifications
Typical Properties
TENSILE STRENGTH
Typical 24 ksi / 166 MPa
YIELD STRENGTH
Typical 15 ksi / 105 MPa
PERCENT OF ELONGATION
3%
BRINELL
65
COEFFICIENT OF THERMAL EXPANSION (average)
68 to 212 °F (20 to 100 °C):
13.1 x 10-6 in/in ·°F
23.6 x 10-6 m/m · K
68 to 392 °F (20 to 200 °C):
13.6 x 10-6 in/in ·°F
24.5 x 10-6 m/m · K
THERMAL CONDUCTIVITY
0.34 cal/cm · s · °C
142 W/m · K
82 Btu/ft · h · °F
ELECTRICAL CONDUCTIVITY, IACS
36%
MODULUS OF ELASTICITY
10.3 x 106 psi / 71,000 MPa
Mill Sizes
STANDARD THICKNESSES
1/4”- 4”
6 - 100mm
STANDARD WIDTHS
48.5” & 60.5”
1232 & 1537mm
STANDARD LENGTHS
96.5”, 120.5” & 144.5”
2451, 3061 & 3670mm
Non-standard thicknesses, widths and lengths may be available upon request.
Tolerances
SURFACE
Each side is machined to a maximum 20 microinch or 0.50 micron smoothness.
EDGE CONDITION
Width:
Milled or Saw Cut
Length:
Saw Cut
MILL PLATE
Length tolerance:
+1/2” -0. / +13mm -0.
Width tolerance:
+1/4” -0. / +7mm -0.
THICKNESS TOLERANCE
The tolerance for any thickness is
±.005” /±.127mm
FLATNESS TOLERANCE:
Specified plate thickness maximum variation:
3/4” and over:
.005”
19mm and over:
.127mm
1/4” to 5/8”:
.015”
6mm and over:
.381mm
Flatness tolerances at the mill are measured using a laser system and/or granite flatness table.
The tolerances apply to both standard mill origin plate and to cut blanks when proper cutting
techniques and equipment are used.
