High Performance Mould Materials
Overview
•
Mould weight is significantly reduced due to density being one third that of steel.
Moulds are easier to handle and exert less strain on processing machinery.
•
High metal removal weights are possible due to excellent machinability.
Moulds can typically be made in one third the time taken for steel.
•
Polishing is quick and easy. High standards of microstructural integrity mean high
quality mirror finishes can be obtained enabling Alumec
®
products to be used in
optically critical applications.
•
Thermal conductivity is typically four to five times that of steel. Simpler cooling
circuits may be designed or cycle times reduced. Temperature differences
throughout the mould are minimised so reducing moulded part distortion.
•
Easy surface to treat. Processes such as chemical nickel, hard chrome and hard
anodising can provide enhanced surface properties.
•
Easy to spark and wire erode. Metal removal rates are at least four times that of steel.
•
Easy to photo-etch, Response is even and uniform throughout enabling parts to
be easily matched.
Alumec 79
®
•
Excellent strength, machinability and stability during machining.
•
Strength levels do not reduce as rapidly as in 7075-T651, especially in thick sectors.
•
Through thickness hardness consistency is better than 7075-T651.
•
Easily repair welded.
•
Available as plate up to 305mm thick.
•
Used in a wide variety of applications, including injection and blow moulding.
Alumec 89
®
•
Higher strength levels and better through thickness hardness consistency than
Alumec 79
®
.
•
Used in more demanding applications where greater performance is required,
especially increased wear resistance and superior polishability.
•
Available as plate up to 480mm thick.
•
Used extensively in injection and blow moulding.
Alumec 100
®
•
Derived from advanced aerospace technology.
•
Improved Toughness.
•
Plate thickness up to 305mm.
