Mild steel
Galvanised steel
Aluminium
35
Code
Ø mm
1809003SC
42.4
Code
Ø mm
1809005
42.4
Code
1809008F
Code
Ø mm
1809007C
42.4
Code
Ø mm
1809009R
42.4
Code
Ø mm
1809009L
42.4
Code
Ø mm
1809012
42.4
Code
Ø mm
1809013
42.4
Bracket Single Mount
To hold light stick in position
Bracket Two Way Double Mount
For use with cranked elbow or handrail adaptor
10mm
10mm
8mm 10mm
Cranked Elbow and Wall Plate
For use with double mount
8mm
Handrail Adaptor and Stem
For use with single and double mount
8mm
Wall Return Bracket - Right
For use at the end of a run to return wires to the wall
Wall Return Bracket - Left
For use at the end of a run to return wires to the wall
Corner Post Fitting - Universal
Post Tee - Universal
LUMENRAIL - COMPONENTS
