28
Code
Weight Kg
For Use With
Size mm
1855101100925
25.44
Fully assembled posts or
401 or 402 series clamp 1100 x 925 x 10
Code
Weight Kg
For Use With
Size mm
18551510001075
40.32
Base fixed channels set
onto finished floor line
1000 x 1075 x 15
18551910001075
51.42
1000 x 1075 x 19
18551510001175
44.07
Side fixed channels set
100mm below finished
floor line
1000 x 1175 x 15
18551910001175
56.20
1000 x 1175 x 19
Code
Weight Kg
For Use With
Size mm
185617510001075
47.04
Base fixed channel set
onto finished floor line
1000 x 1075 x 17.5
185621510001075
57.76
1000 x 1075 x 21.5
185617510001175
51.41
Side fixed channel set
100mm below finished
floor line
1000 x 1175 x 17.5
185621510001175
63.15
1000 x 1175 x 21.5
1100mm
925mm
1000mm
1000mm
1075 or 1175mm
1075 or 1175mm
10mm Thick Toughened Monolithic Clear Float Glass
Use with our fully assembled glass clamp posts
15 & 19mm Thick Toughened Monolithic Clear Float Glass
Use with our aluminium glass channel systems such as PanelGrip & PanelWedge
17.5 & 21.5mm Thick Toughened & Laminated Clear Float Glass
Use with our aluminium glass channel systems such as PanelGrip & PanelWedge
• Suits standard height uprights installed at 1200mm centre to centre
• Polished edges
• 3mm radiussed corners
• No security pin holes required
• Use with type 401 & 402 glass clamps
• See next page for fitting advice
• Suits our PanelGrip & PanelWedge types of channel – base or side fixed
• Polished edges
• 5mm radiussed corners
• Handrail will be required
• See next page for fitting advice
• Suits our PanelGrip & PanelWedge types of channel – base or side fixed
• Polished edges
• 3mm radiussed corners
• See next page for fitting advice
PRO-GLASS - STANDARD PANELS
