Angle
304S31 & 316S11/S31
(1.4301 + 1.4404)
Size Weight
(mm)
per metre (Kg)
20 x 20 x 3 0.88
25 x 25 x 3 1.12
25 x 25 x 5 1.78
25 x 25 x 6 2.09
30 x 30 x 3 1.35
30 x 30 x 5 2.17
30 x 30 x 6 2.56
40 x 40 x 3 1.83
40 x 40 x 5 2.96
40 x 40 x 6 3.51
50 x 50 x 3 2.3
50 x 50 x 5 3.75
50 x 50 x 6 4.46
Welded Mesh
TYPE 304 & 316
Sheet
TYPE 316 (1.4404)
MIRROR POLISH FINISH
Size Weight
(in)
per panel (Kg)
96” x 48” x
1
⁄
2
” x
1
⁄
2
” x 16 swg 6.5
96” x 48” x 3” x
1
⁄
2
” x 10 swg 16
96” x 48” x 3” x
1
⁄
2
” x 12 swg 11
96” x 48” x 1” x 1” x 10 swg 13
96” x 48” x 1” x 1” x 12 swg 9.5
96” x 48” x 1
1
⁄
2
” x 1
1
⁄
2
” x 10 swg 9
96” x 48” x 2” x 2” x 10 swg 7
96” x 48” x 2” x 2” x 12 swg 5
Size Weight
(mm)
per sheet (Kg)
2500 x 1250 x 0.9 23
2500 x 1250 x 1.2 30.7
2500 x 1250 x 1.5 38.4
2500 x 1250 x 2.0 51.2
2500 x 1250 x 2.5 63.9
2500 x 1250 x 3.0 77.5
2500 x 1250 x 5.0 125
2500 x 1250 x 6.0 150
2500 x 1250 x 8.0 200
Size Weight
(mm)
per metre (Kg)
50 x 50 x 10 7.11
60 x 60 x 5 4.58
60 x 60 x 6 5.4
60 x 60 x 10 8.69
70 x 70 x 6 6.35
70 x 70 x 10 10.3
75 x 75 x 6 7.37
75 x 75 x 10 11.95
80 x 80 x 6 7.89
80 x 80 x 10 12.8
100 x 100 x 6 9.2
100 x 100 x 10 15
