www. bl ackburnsmeta l s . com
Plate
1D FINISH
ASTM A240, ASME
SA240: 304, 304L, 316, 316L
EN10088-2: 1.4301, 1.4307
1.4401, 1.4404
Size Weight
(mm)
per plate (Kg)
2000 x 1000 x 3 51
2500 x 1250 x 3 79.7
3000 x 1500 x 3 115
2000 x 1000 x 4 68
2500 x 1250 x 4 106
3000 x 1500 x 4 153
2000 x 1000 x 5 85
2500 x 1250 x 5 133
3000 x 1500 x 5 191
4000 x 2000 x 5 340
2000 x 1000 x 6 102
2500 x 1250 x 6 159
3000 x 1500 x 6 230
Size Weight
(mm)
per plate (Kg)
4000 x 2000 x 6 408
2500 x 1250 x 8 213
3000 x 1500 x 8 306
4000 x 2000 x 8 544
2500 x 1250 x 10 266
3000 x 1500 x 10 383
4000 x 1500 x 10 510
4000 x 2000 x 10 680
2500 x 1250 x 12 319
3000 x 1500 x 12 459
4000 x 1500 x 12 612
4000 x 2000 x 12 816
Quarto Plate
1D FINISH
ASTM A240, ASME
SA240: 304, 304L, 316, 316L
EN10088-2: 1.4301, 1.4307
1.4401, 1.4404
BS1501 PT3: 304S31, 304S11
316S31, 316S11
Thickness Unit Weight
(mm)
per sq metre (Kg)
5 42.5
6 51
8 68
10 85
12 102
15 128
16 136
20 170
22 187
25 213
30 255
32 272
Stainless
Treadplate
PATTERN B
AISI 304, ASTM A793/96
Thickness Unit Weight
on base (mm)
per plate (Kg)
3000 x 1000 x 3 78
3000 x 1250 x 4.5 143
3000 x 1250 x 6 180
3000 x 1250 x 8 210
Thickness Unit Weight
(mm)
per sq metre (Kg)
35 298
40 340
45 383
50 426
55 468
60 510
65 553
70 596
75 638
90 765
100 850
125 1063
