Mild steel
Galvanised steel
Aluminium
15
Code
Ø mm
1804731C
42.4
1804731D
48.3
1806731C
42.4
1806731D
48.3
Code
Ø mm
1804732C
42.4
1804732D
48.3
1806732C
42.4
1806732D
48.3
Code
Ø mm
1804733C
42.4
1804733D
48.3
1806733C
42.4
1806733D
48.3
Code
Ø mm
1804737C
42.4
1804737D
48.3
1806737C
42.4
1806737D
48.3
+ or - 5°
• All stainless posts are satin polished
• Tested to 1.5kN with a welded base fitting
• Designed to give 1100mm handrail height when installed with our components on flat surfaces
• Welded base fitting with cover plate & rubber ‘O’ ring to secure cover plate
• Adjustable spigot for flat or raked applications
• Post with glass clamps are ready to accept 10mm glass. 8mm rubbers available
• We sell glass from stock to suit 1200mm post centres
• Additional rubbers for different glass thickness available to purchase if required
• Special 5
°
variable fixing bolt to allow flexibility of alignment when fixing glass
• 7 hole post fitted with 12mm bar/tube holders
ALL POSTS FOR GLASS CLAMPS HAVE:
Welded Base Fitting complete
with Rubber 'O' Ring + Cover
Glass Clamp (for 10mm Glass)
Variable Fixing Bolt
TESTED
TO
1.5kN
+/- 5°
Adjustable Spigot
A range of pre-assembled posts designed to cut installation times
End Post
Mid Post
Corner Post
7 Hole Post
80mm
80mm
52mm
132mm
275mm
275mm
PRE - ASSEMBLED POSTS
