Mild steel
Galvanised steel
Aluminium
17
Code
Size mm
1801405F
80 x 40 x 6
1801407F*
80 x 40 x 6
1806405F
80 x 40 x 6
Code
Size mm
1801409IC
80 x 80 x 40 x 6
1806409IC
80 x 80 x 40 x 6
Code
Size mm
1801406F
120 x 40 x 6
1801408F*
120 x 40 x 6
1806406F
120 x 40 x 6
Code
Size mm
1801409EC
80 x 80 x 40 x 6
1806409EC
80 x 80 x 40 x 6
Code
Size mm
1801409F
160 x 40 x 6
1806409F
160 x 40 x 6
*With stainless steel discs
*With stainless steel discs
An economic alternative to the traditional glass clamp system. They not only look good, but are easy to
install with no on-site fixing and if required the mild steel clamps can be galvanised after fabrication and
powder coated.
Short Single
Specification:
• 316 Dome Nut
• Rubber Washer
• 6mm Plate + Disc
• Suits 8 - 10mm Thick Glass
• Mild Steel + Stainless Steel
• Countersunk Stainless 316 8mm Bolt
Additional Accessories:
Code: 1899405NS
Nylon Spacer
Code: 1899405RD
Round Disc (S/S 316)
Code: 1899405RI
Rubber Inlay
Code: 1899405TA
Threaded Assembly (S/S 316)
(Includes bolt and hex dome nut)
Exploded View
Reverse View
Long Single
Straight Double
Internal Corner
External Corner
GLASS CLAMPS - WELDABLE
