The PanelGrip
®
System utilises a unique locking mechanism of high-strength aluminium and PVC
isolators combined with a specially designed aluminium Shoe Moulding. When assembled with
15 - 21.5mm tempered monolithic, or tempered laminated glass, PanelGrip enables the installer to
fabricate a structural Glass Railing System with a significant reduction in labour.
Side Fix
Base Fix
1.
Place Dry Mount Grips into
shoe moulding
2.
Insert PanelGrip on the
opposite side
3.
Tighten PanelGrip mechanism
4.
Confirm alignment and fully
tighten
The benefits of PanelGrip are:
• Adjustable
The PanelGrip design enables the system to be simply
adjusted and readjusted when installed
• Reduce labour costs
No sealing of the shoe, no setting blocks, no plumbing of
glass, no multiple pours of cement, no waiting for cement
to cure; no messy clean-up
• Simple to install
All you need is an Allen key for installation or removal
of glass
TESTED
TO
1.5kN
U.S. Patent 7,730,682; Other patents pending
A Balustrade
Revolution!
Visit our website to see how simple this system is to install and also for test data and loading calculations.
PANELGRIP BALUSTRADE SYSTEM
