Internal
External
Zinc
304
316
22
Glass Thickness mm Length
Base Fix Channel
Side Fix Channel
Grip
12
3.048m (10ft)
1805460B
1805460S
1805461B
15
1805460B
1805460S
1805461
17.5
1805466B
1805466S
1805461B
19 & 21.5
1805466B
1805466S
1805461
Channel fixing holes are 14mm at 203.2mm (8") centres to suit a 12mm bolt
Please order 5 grips per metre
PanelGrip is supplied non-anodised
Code
Product
Length m
Size mm/Type
18054653
Stainless Cladding
3.0
105 x 20.6 x 0.8
1805467
460 Series End Cap
-
Satin
1805468
466 Series End Cap
-
Satin
1805453
Cladding Tape
50
Double Sided
1805463
Gasket - Full Roll for use with cladding
30.48
28 x 6
18054631
Gasket - Metre for use with cladding
1.0
26 x 6
1805462
Gasket - Full Roll for use without cladding
76.2
18 x 14
18054621
Gasket - Metre for use without cladding
1.0
18 x 4
Code
Product
1805464
Plumbing Bar with Spirit Level
1805456
Shims 1m long 3mm thick
(pack of 9)
PanelGrip
Levelling
Device
Adjustment
Rods
Shims
(See Page 24)
Cladding
Gasket
63.6
42.8
14.2
10.4
82.8
104.9
28
22.1
14.2
69.9
49.1
14.2
10.4
82.8
104.9
28
22.1
14.2
Aluminium Channel + Grip Selector
Cladding + Gasket Selector
460 Series
466 Series
Grip
Cladding
Cladding
End Cap
Levelling Device
Gasket for use without
Cladding
Suitable for 12 & 15mm glass
Suitable for 17.5, 19 &
21.5mm glass
Gasket for use with
Cladding
For all fixings and Allen keys see pages 52 - 55.
SEE PAGE 61 FOR
GLASS LOADING
GUIDELINES.
PANELGRIP BALUSTRADE SYSTEM
