Internal
External
Zinc
304
316
24
Code
Fixing
Length m
1805450B
Base
3
1805450S
Side
3
15mm glass requires 22mm cladding (wedge side) and 26mm (packer side)
17.5 - 19mm glass requires 22mm cladding on both sides
21.5 - 25mm glass requires 22mm cladding (wedge side) and 16mm (packer
side)
Code
Description
180599001BUY
Wedge Removal Tool to Buy
Code
1805453
Code
1805454
Code
1805455
Code
1805456
Code
Finish m x mm Length m
180545216
Satin
16
3
180545222
Satin
22
3
180545226
Satin
26
3
Code
Glass Thickness mm
Sets
180545115
15
4 per metre
1805451175
17.5
4 per metre
180545119
19.0
4 per metre
1805451215
21.5
4 per metre
180545125
25.0
4 per metre
64
83.1
18.6
101.7
16
32
15.2
28
15.2
x
Side profile of an installation
Aluminium Channel
Stainless Cladding
Channel Spacer
5 per metre
Tape for fixing Cladding
50m roll
Cladding End Cap
Satin finish
Shims
1m length, pack of 9
Bottom/Side Isolator & AluminiumWedges
For fixings see page 54
450 Series
Please consult a structural engineer to ensure your designs test data conforms to loading requirements.
Mirror finish available to order
PANELWEDGE BALUSTRADE SYSTEM
